Discover the product

Description

3-Channel ECG SE-300B Edan

General characteristics:
• 144 ECG memory.
• ECG recordings: manual and automatic with CSE/AHA/MIT tested interpretation.
• Recording of 12 leads simultaneously with 24-bit converter.

Digital filtration: Bandwidth 0.05 – 0.15 – 0.25 – 0.32 – 0.5 – 0.67 Hz. Narrowband: 25/35/45 Hz/OFF.
• Main power supply: 75/100/150 Hz.
• Sensitivity / amplitude: 2.5/5/10/20,10/5, AGC (mm/mV).
• Screen: 320 x 240 LCD.
• Built-in high-resolution thermal printer or possibility of connecting an external printer to print the 12 leads on A4.
• Paper feed speed: 5, 6.25, 10, 12.5, 25 or 50 mm/s.
• Connectivity: Ethernet/RS232/USB.
• Ability to export data in PDF directly to a USB stick.

Comes with:
• 1 patient cable.
• 10 banana plug wires.
• 6 precordial electrodes.
• 4 straps with integrated electrodes.
• 1 bundle of paper.
• 1 user manual.
• 1 spare fuse.
• CE / TÜV validation.

Weight : 2.5 kg
Warranty : 3 years
Power supply : 220-110 V ~ 50/60 Hz mains or lithium-ion battery

Description

3-Channel ECG SE-300B Edan

General characteristics:
• 144 ECG memory.
• ECG recordings: manual and automatic with CSE/AHA/MIT tested interpretation.
• Recording of 12 leads simultaneously with 24-bit converter.

Digital filtration: Bandwidth 0.05 – 0.15 – 0.25 – 0.32 – 0.5 – 0.67 Hz. Narrowband: 25/35/45 Hz/OFF.
• Main power supply: 75/100/150 Hz.
• Sensitivity / amplitude: 2.5/5/10/20,10/5, AGC (mm/mV).
• Screen: 320 x 240 LCD.
• Built-in high-resolution thermal printer or possibility of connecting an external printer to print the 12 leads on A4.
• Paper feed speed: 5, 6.25, 10, 12.5, 25 or 50 mm/s.
• Connectivity: Ethernet/RS232/USB.
• Ability to export data in PDF directly to a USB stick.

Comes with:
• 1 patient cable.
• 10 banana plug wires.
• 6 precordial electrodes.
• 4 straps with integrated electrodes.
• 1 bundle of paper.
• 1 user manual.
• 1 spare fuse.
• CE / TÜV validation.

Weight : 2.5 kg
Warranty : 3 years
Power supply : 220-110 V ~ 50/60 Hz mains or lithium-ion battery

Edan par Edan

ECG 3 Channel SE-300B - EDAN

Prix habituel
1.244,28€
Prix soldé
1.244,28€
Prix habituel
Taxe inclu. Frais de port calculés dans le panier.

Prix HT. Prix TTC affichés lors de la validation de commande.

En rupture de stock
Order before 4pm and your order will be shipped today*

Translation missing: en.products.product.sku:440.001

Secure CB payment by Up2Pay from Crédit Agricole
Free delivery from 100€ purchase including tax
Delivery to your office, relay point or home
